Chapter 15 System Function Setting RIGOL
MSO2000A/DS2000A User’s Guide
15-7
USB Device
This oscilloscope can communicate with PC or PictBridge printer via the USB Device
interface at the rear panel. You need to set the oscilloscope to make it match with
different device types.
Press Utility  IO Setting  USB Device and use to select the desired
device type.
 Computer: in this type, the oscilloscope can communicate with the PC.
 PictBridge: in this type, the oscilloscope can communicate with the PictBridge
printer.
GPIB Address
When using the GPIB mode to control the oscilloscope, you need to extend a GPIB
interface for the oscilloscope using the USB-GPIB interface converter (need to be
ordered separately).
To set the GPIB address of this interface, press Utility  IO Setting  GPIB and
use to input the desired address. The default is 1 and the range is from 1 to 30.
