RIGOL Chapter 14 Store and Recall
14-10 MSO2000A/DS2000A User’s Guide
To Create a New File or Folder
This operation is only valid in external storage. Before using external disk, make sure
that the USB storage device is connected correctly.
First, press Storage  Disk.Manage and use to select and open the external
disk (“Disk D”). Then, select the desired directory under which to create a new file or
folder. The default is the root directory of the USB storage device. Lastly, press File
Type to select the desired file type and press New File or directly press New
Folder to turn on the interface as shown in the figure below.
Figure 14-7 To Create a New File or Folder
This oscilloscope supports Chinese/English input method. The file name or folder
name can contain letters, numbers, underscores, spaces and Chinese characters and
the length of the characters is limited to 31 bytes. The following part introduces how
to input a file name or folder name using Chinese/English input method.
Operation Tip
D
uring the name input, use the menu softkeys to select different operation areas,
then turn to select the desired content and press down to input the
content selected.
