RIGOL Chapter 13 Signal Source
13-16 MSO2000A/DS2000A User’s Guide
6. Time
Press Time to set the duration of the current point. This setting is limited by the
times of the previous point and following point. The time of point 1 is fixed at 0 s.
For the setting method, please refer to the introduction in “
Parameter Setting
Method”.
7. Insert
Press Insert to insert a new waveform point between the current point and the
next point.
8. Delete
Press Delete to delete the current point from the waveform and connect the
remaining points.
Note: Point 1 cannot be deleted.
9. Done
Press Done to finish editing the current waveform.
10. Save
Press Save to enter the file store interface. Please refer to the introduction in
“
Store and Recall” to save the current waveform file in “.arb” format in the
internal memory (you can overwrite the original file or save the current
waveform again).
You can select the arbitrary waveforms in the internal or external memory for
output. For the details, refer to the introduction in “To Select Waveform”.
To Edit Waveform
You can edit the waveform currently stored in the volatile memory of the instrument.
Press Edit to enter the waveform editing menu.
1. Interp
Press Interp to turn on or off the interpolation mode between the points of the
waveform.
