RIGOL Chapter 11 Waveform Record
11-2 MSO2000A/DS2000A User’s Guide
Waveform Record
When the waveform record function is turned on, waveforms from all the channels
currently turned on will be recorded. Press Utility  Record  Mode and use
to select “Record” to open the waveform record operation menu.
1. End Frame
Press End Frame; use or the inner knob of the navigation knob to adjust
the the desired number of frames to be recorded at a relatively smaller step or
turn the outer knob of the navigation knob to adjust the the desired number of
frames to be recorded at a relatively larger step. The available range is from 1 to
the maximum number of frames that can be recorded currently (displayed in
Total Frames).
2. Record Operation
Waveform recod can be realized via the menu or the shortcut buttons at the
front panel.
Menu Front Panel
Press Operate and select “●” to
start recoding.
Press ; the backlight goes on (in red)
and starts to flash, indicating that the
record is started.
When the record is finished, “●”
changes to “■” automatically.
You can also select “■” manually
to stop recording.
When the record is finished,
goes off
automatically and
goes on (in
orange). You can also press
directly to
stop recording.
3. Interval
Press Interval; use or the inner knob of the navigation knob to adjust the
time interval at a relatively smaller step or turn the outer knob of the navigation
knob to adjust the time interval at a relatively larger step. The range available is
from 100 ns to 10 s.
4. Total Frames
The menu shows the maximum number of frames that can be recorded
currently.
The number of points of each frame is the current memory depth
[1]
. As the
