Chapter 6 MATH and Measurements RIGOL
MSO2000A/DS2000A User’s Guide 6-27
All Measurement
All measurement could measure all the time and voltage parameters (each
measurement source has 21 items, measurements can be performed on CH1, CH2
and MATH at the same time) of the current measurement source and display the
results on the screen. Press Measure  Display All to enable or disable the all
measurement function. Press Measure Source and use to select the channel(s)
to be measured (CH1, CH2 and MATH).
When multiple “All Measurement” source channels are selected at the same time, the
measurement results (the measurement results are in the same color as the channel)
will be displayed on the screen from top to bottom in CH1, CH2, and MATH order. If
the measurement result is displayed as “*****”, there is no signal input into the
current measurement source or the measurement result is out of the valid range (too
large or too small).
Note:
 When the all measurement function is enabled, “One-key Measurement” is still
valid.
 “To Clear the Measurement” will not clear the measurement results of the all
measurement function.
