Chapter 7 Digital Channel RIGOL
MSO2000A/DS2000A User’s Guide 7-3
To Turn on/off the Digital Channel
Press LA On/Off to enter the digital channel/group “On/Off” setting menu.
Press D7-D0 to turn on or off channels D7-D0 at the same time.
Press D15-D8 to turn on or off channels D15-D8 at the same time.
Press Sel CH to turn on the channel list. Rotate to select any channel and
press to turn on or off the channel. You can also press Sel CH continuously
to turn on or off the selected channel. Channels turned on are marked with
and channels that are not turned on are marked with
. You can turn on or off
any channel via the channel selection menu.
Note: When you have turned off channels D7-D0 at the same time using
D7-D0, you can still turn on or off any of the channels via the channel selection
menu. When you have turned on channels D7-D0 at the same time using
D7-D0, the channels in the list switch to ON status automatically. The situation
of channels D15-D8 is similar.
Press Group, rotate to select any channel group and press to turn on or
off all the channels in the group at the same time. You can also press Group
continuously to turn on or off the selected group. The channel groups turned on
are marked with
and the channel groups that are not turned on are marked
with
.
Note: Only user-defined digital channel groups can be selected.
For how to define channel groups, please refer to the introduction in “Group
Set”.
