RIGOL Chapter 11 Waveform Record
11-12 MSO2000A/DS2000A User’s Guide
Analysis Based on Trace
Press Analyze and select “Trace”. Then, set the templet used in analysis based on
trace through the method below.
1. Trace
Press Trace to select the creation method of analysis templet.
 Current Frame: select the current frame as the analysis templet.
 Average: select the average of the current data frame as the analysis
templet.
2. Setup Template
Press SetupTemplate to configure the templet immediately. After the analysis
starts, the oscilloscope compares each frame with the templet and determines
whether error frame exists according to the threshold currently set.
3. TemplateDisp
Press TemplateDisp to enable or disable templet display.
