Roland VS-2000 Owner's Manual Addendum

6—VGA Main Display CH VIEW Screens
Roland VS-2000 Owner’s Manual, Version Two Addendum www.RolandUS.com 61
Track Channel Parameter Strip
1. Channel Name
2. STATUS Button
3. V.TRACK Selector
4. PHASE Button
5. ATT Knob
6. GROUP Selector
7. CH LINK Button
8. FDRLINK Button
9. AUTOMIX STATUS Button
Click STATUS repeatedly to set the status of the
corresponding hard disk recorder track. This is the
same as clicking the track channel’s TRACK STATUS
button on the VS-2000.
To select a different V-Track, click V.TRACK and
select the desired V-Track from the pop-up menu,
described on Page 47.
Click PHASE—so it’s lit—to reverse the phase
polarity of the channel’s signal.
To adjust the level of the signal coming into the track channel from
the hard disk recorder, drag the ATT knob up or down as desired—
the readout beneath the knob shows the current amount of
attenuation.
To assign the track channel to a fader group, click GROUP and
select the desired fader group from the pop-up menu.
To link the channel to its odd/even partner so that any changes
made to one channel affect both, click CH LINK to turn it on.
Click FDRLINK—so it’s lit—to link the current channel’s fader to its
odd/even partner so their levels can be set by moving either fader
while their other parameters remain independently controllable.
Click the AUTOMIX STATUS button repeatedly to set the channel’s
status as desired when Automix mode is on.
2.
1.
9.
8.
7.
6.
5.
4.
3.
176
149
153
151
153
150
154
343
VS2000v2Add.book 61 ページ ２００５年４月８日 金曜日 午後２時２４分
