7—Mixer Views
70 www.Roland.com Roland VS-2000 Owner’s Manual, Version Two Addendum
AUX and FX Send Sliders
In the Input Mixer/Master Block and Track Mixer/FX Return Mixer, input, track and FX
return channels all sport Aux and FX send sliders. These sliders allow you to send the
desired amount of a channel’s signal to any of the two Aux and six FX busses, and show
you at a glance each send level. To set an Aux and FX send level, click and drag its slider
with your mouse to the desired position.
A slider’s color provides information about its
Aux send. When a slider is:
•
blue
—the Aux send is on and set to Post.
•
red
—the Aux send is on and set to Pre.
•
gray
—the Aux send is turned off.
•
black
—the send is turned all the way down.
You can change the Aux and FX bus’s pre/post setting:
• on any channel’s VGA CH VIEW screen (Page 59).
• in the Input Mixer/Master Block view (described on Page 71).
• in the MASTER EDIT window available in the VGA main display’s MIXER menu
(Page 32).
• in the track controls area in the playlist (Page 46).
When an odd/even pair of Aux and FX busses is linked, the slider for the even bus is
replaced by a panning handle, as described on Page 73.
Blue=On, Pst
Red=On, Pre
Gray=Off
Black=No level
AUX Send
FX Send
VS2000v2Add.book 70 ページ ２００５年４月８日 金曜日 午後２時２４分
