Roland VS-2000 Owner's Manual Addendum

7—Mixer Views
74 www.Roland.com Roland VS-2000 Owner’s Manual, Version Two Addendum
Track Mixer/FX Return Mixer View
Select TRACK MIXER/FX RTN MIXER from the MIXER menu to view all of the
VS-2000’s 18 track channel and six FX return channel strips at once on the VGA.
Track Channel Strips
1. DYNAMICS (DYN) On/Off
2. EQ On/Off
3. AUX and FX Send Sliders
4. MUTE (M) Button
5. SOLO (S) Button
6. AUTOMIX STATUS (A) Button
Click this button to turn the channel’s dynamics processor on—when
the button’s lit—or off. See Page 63.
To turn the channel’s EQ on or off, click this button. When it’s lit, the
EQ’s on. See Page 63.
Set the amount of the channel’s signal sent to an Aux and FX bus by
adjusting the corresponding AUX send slider. With linked Aux busses, a
panning handle replaces the even-numbered Aux bus’s slider (Page 73).
To mute the channel, click this button so it’s lit. To un-mute the channel,
click the button again.
To solo the channel, click the SOLO button to light it. To un-solo the
channel, click the button again.
When Automix is turned on, repeatedly click the AUTOMIX STATUS
button to set the channel’s Automix status.
FX Return MixerTrack Mixer
1.
2.
3.
5.
7.
9.
10.
4.
6.
8.
AUX Send
FX Send
151
141
142
343
VS2000v2Add.book 74 ページ ２００５年４月８日 金曜日 午後２時２４分

Roland VS-2000 Specifications

General

Type	Digital Audio Workstation
A/D/A Conversion	24-bit
MIDI	MIDI In/Out
Simultaneous Recording Tracks	8
Sampling Frequency	44.1kHz, 48kHz
Effects	Built-in effects including reverb, delay, chorus, and more
Inputs	8 XLR/TRS combo inputs, 2 RCA inputs
Outputs	2 RCA outputs, headphone output
Storage	Internal hard drive (40GB), optional CD-RW drive
Display	LCD
