Roland VS-2000 Owner's Manual Addendum

7—Mixer Views
Roland VS-2000 Owner’s Manual, Version Two Addendum www.RolandUS.com 71
Input Mixer/Master Block View
Select INPUT MIXER/MASTER BLOCK from the MIXER menu to view all of the
VS-2000’s 10 input channel strips and MASTER BLOCK settings at once on the VGA.
Input Channel Strips
1. DYNAMICS (DYN) On/Off
2. EQ On/Off
3. AUX and FX Send Sliders
4. MUTE (M) Button
5. SOLO (S) Button
Click this button to turn the channel’s dynamics processor on—so the
button’s lit—or off. See Page 63.
To turn the channel’s EQ on or off, click this button. When it’s lit, the
EQ’s on. See Page 63.
Set the amount of the channel’s signal sent to an Aux and FX bus by
adjusting the corresponding Aux and FX send slider. With linked Aux
and/or FX busses, a panning handle replaces the even-numbered Aux
and/or FX bus’s slider (Page 73).
To mute the channel, click this button so it’s lit. To un-mute the channel,
click the button again.
To solo the channel, click the SOLO button to light it. To un-solo the
channel, click the button again.
Master BlockInput Mixer
1.
2.
3.
5.
7.
8.
9.
4.
6.
AUX Send
FX Send
151
141
142
