Siemens SIMATIC IPC477D User Manual

Expanding the device and assigning device parameters
6.6 Installing and removing a CFast card
SIMATIC IPC477D, IPC477D PRO
Operating Instructions, 11/2016, A5E31347228-AF
147
Procedure
Removal
1.
For built
-in unit: Remove the indicated
screws and lift up the retainer
.
For PRO device: Remove the marked
screws and lift off the mounting bracket.
2.
Press on the CFast card in the direction
of the arrow.
The C
Fast card moves approximately
5 mm out of the slot.
3.
Remove the CFast card.
