Siemens SIMATIC IPC477D User Manual

Technical information
8.4 Technical specifications
SIMATIC IPC477D, IPC477D PRO
208 Operating Instructions, 11/2016, A5E31347228-AF
8.4
Technical specifications
8.4.1
Built-in unit
8.4.1.1
General technical specifications
Weight of touch device (without expan-
sions):
Resistive touch screen Capacitive touch screen
• Touch device, 12" display
• Touch screen device, 15" display
• Touch screen device, 19" display
• Touch screen device, 22" display
• Approximately 3200 g
• Approximately 4920 g
• Approximately 6400 g
• Approximately 7000 g
• -
• Approximately 5200 g
• Approximately 6700 g
• Approximately 7900 g
Weight of touch/key device (without ex-
tensions):
• Touch/key device, 15" display • Approx. 5750 g • -
For device with expansion cards, the
weight increases accordingly:
• Expansion: PCIe card
• Expansion: DVD drive
• Expansion: PCIe card and DVD drive
• Approximately 150 g
• Approximately 420 g
• Approximately 580 g
Power supply
1
• 24 V DC (-20 % / +20 %)
1
• 100-240 VAC (-15 % / +15 %); 47-63 Hz
Short-term voltage interruption
according to Namur
Min. 20 ms at 20.4 V (DC)
Min. 20 ms at 93 V (AC); max. 10 events per hour;
min. 1 s recovery time
Degree of protection
• IP 20 to IEC 60529 (enclosure)
• IP 65 (front)
Quality assurance
In accordance with ISO 9001
1
The generation of the supply voltage by the line-side power supply must be realized as safety
extra-low voltage with safe electrical isolation, isolated according to IEC 60364-4-41 or as SELV
according to IEC/UL/EN/DIN-EN 60950-1. The supplying source must be fused for a power rating
< 240 VA; recommended fuse rating ≤ 8 A.
