8.4 Technical specifications
SIMATIC IPC477D, IPC477D PRO
212 Operating Instructions, 11/2016, A5E31347228-AF
COM 1 and COM 2 RS 232, max. 115 kbps, 9-pin, D-sub connector
Connection of display devices with DVI connection
Display port (DPP) Connection of display devices with DPP connection
USB Back of device:
• 4 x USB 3.0, a maximum of 2 can be operated in high-current
mode at the same time
Front of device (only for devices with resistive touch screen with
15", 19" and 22" display):
• 1 × USB 2.0, high current
PROFIBUS/MPI
• Transmission rate
• Operating modes
9-pin, 2-row, electrically isolated, D-sub socket, CP 5622 com-
patible
• 9.6 kbps to 12 Mbps
• DP master: DP-V0, DP-V1 with SOFTNET-DP
DP slave: DP-V0, DP-V1 with SOFTNET-DP slave
PROFINET 3 x RJ45 connection, CP 1616-compatible onboard port based
on ERTEC 400
10/100 Mbps, electrically isolated
Ethernet
1
2 x RJ45 connection, Intel 82579LM and Intel 82574L
10/100/1000 Mbps, electrically isolated, teaming-capable
2
or
For PROFINET variants:
1 × Ethernet RJ45, Intel 82579LM
Slot for PCIe expansion cards Only for device with expansions:
• 1 × PCIe-x4 expansion card can be used
• Max. permissible power loss: 5 W
For unique labeling, the Ethernet ports are numbered on the enclosure. The numbering by the
operating system can differ.
Teaming can be set and initiated in the configuration interface. In teaming operation, jumbo
frames, e.g. for the camera application, are not supported.
