Commissioning (software)
4.6 Creating and testing an axis
SIMOTION D410
104 Commissioning Manual, 02/2012
3. Complete your SIMOTION application, for example, by creating axis functions and
SIMOTION execution programs.
4. Compile the project and download it to SIMOTION D410.
Note
Note that only one real axis can be used on a SIMOTION D410.
4.6.2 Creating an axis with the axis wizard
Overview
The TO axis provides the user with the technological functionality and the interface to the
drive/actuator. The TO axis processes the motion control commands from the user program
(e.g. MCC) and coordinates the interface to the drives. It executes control and motion
commands and indicates statuses and actual values.
When running through the axis wizard, the basic settings are made for the axis and the
TO axis interconnected to a drive (e.g. SINAMICS Integrated). The following additional
options are available if "Use symbolic assignment" was activated:
● A real axis is interconnected to an already configured drive
● A real axis including drive is created via the axis wizard and the drive interconnected to
the axis
● A real axis is created without assigning this to a drive (assignment is made later)
