Parameter assignment / addressing
3.2 Creating a project and configuring the communication
SIMOTION D410
50 Commissioning Manual, 02/2012
The PG/PC is now connected to the SIMOTION D410 via PROFIBUS. You can configure
and parameterize your system
Note
If you do not use the factory settings, you must configure the PROFIBUS interfaces in HW
Config.
The active state setting of the connection to the PG/PC is visualized only in NetPro!
Inserting a further SIMOTION device
If you insert a further SIMOTION device using "Insert SIMOTION device", the PG/PC
interface selection dialog box is not displayed. Any further SIMOTION device is automatically
connected to the PG/PC via PROFIBUS and a new unique DP address (address 4, 5 ... up
to 125) is calculated.
Additional references
Further information on the topic of "Going online" can be found
● In the online help via the "Contents" tab at
– "Diagnostics" > "Overview of service and diagnostics options" > "Part III" > "Go online"
– "Insert device and connect to target system" > "Go online/offline"
● On the Internet at Internet address
(http://support.automation.siemens.
com/WW/view/en/22016709)
● In SIMOTION Utilities & Applications, FAQ "Online connections to SIMOTION devices".
SIMOTION Utilities & Applications is part of the scope of delivery of SIMOTION SCOUT.
3.2.4 Configuring the Ethernet PG/PC interface (only for D410 PN)
Prerequisites
The following requirements must be satisfied in order to configure the PG/PC interface:
● You have closed the "Insert SIMOTION device" dialog box by pressing "OK" and
configured the properties of the PROFINET interface
● A PG/PC has not yet been configured in the project.
If these prerequisites have been satisfied, you can configure the interface for the PG/PC
connection in the "Interface selection - D410" dialog box.
Proceed as follows to configure the PC Ethernet interface:
