Diagnostics data
6.3 Additional service and diagnostics options
SIMOTION D410
210 Commissioning Manual, 02/2012
Table 6- 6 Functions on the "Diagnostic files" website
Button Function
Create general diagfiles This button saves diagnostic data and non-volatile SIMOTION data in the
...\USER\SIMOTION\HMI\SYSLOG\DIAG directory.
HTML files used for diagnostics purposes are not saved.
Create html diagfiles This button is used to save diagnostics websites on the data carrier. It
should be noted that only those sites that are listed in the
DIAGURLS.TXT file in directory ...\USER\SIMOTION\HMI\SYSLOG\DIAG
are saved (for details, refer to the section titled Backup of diagnostic data
and non-volatile SIMOTION data (Page 201)).
Zip all diagfiles The "zip all Diagfiles" button enables you to compress diagnostics files.
This stores all files and folders in a ZIP file in directory
...\USER\SIMOTION\HMI\SYSLOG\DIAG, while retaining the folder
structure.
Get diagarchive This button is used to save the ZIP archive to connected programming
devices/PCs.
Delete all diagfiles This button is used to delete all data stored in the
...\USER\SIMOTION\HMI\SYSLOG\DIAG directory; the directory itself is
not removed, however.
You can find diagnostic data and non-volatile SIMOTION data on the CompactFlash Card in
the directory \USER\SIMOTION\HMI\SYSLOG\DIAG.
Additional references
For detailed information, refer to the
SIMOTION IT Ethernet-Based HMI and Diagnostic
Functions
Diagnostics Manual.
6.3 Additional service and diagnostics options
6.3.1 SIMOTION Task Profiler application
The SIMOTION Task Profiler is a dedicated application installed parallel to
SIMOTION SCOUT during SIMOTION SCOUT setup. The Task Profiler can be called in
online mode using device diagnostics in SIMOTION SCOUT or the Windows application. In
the event of a malfunction or error, the Task Trace data can be written to a directory or the
CompactFlash Card. They can then be processed using the Task Trace Viewer.
Additional references
For detailed information, refer to the
SIMOTION Task Trace
Function Manual.
