Commissioning (software)
4.1 Overview of commissioning
SIMOTION D410
70 Commissioning Manual, 02/2012
Adaptation
In addition to the symbolic assignment, the automatic adaptation facilitates the configuration
of SINAMICS S110/S120 data as of SIMOTION V4.2. During power-up of the SIMOTION
devices, reference variables as well as drive and encoder data of the SINAMICS S110/S120
are automatically taken over for the configuration data of the SIMOTION technology objects
"TO axis" and "TO external encoder". This data no longer has to be entered in SIMOTION.
For further information refer to
●
SIMOTION SCOUT Basic Functions
Function Manual
●
TO Axis Electrical/Hydraulic, External Encoder
Function Manual
Prerequisite
The symbolic assignment is supported by the TO axis, TO external encoder and the
TO output cam, TO cam track and TO measuring input. The onboard I/Os of a SIMOTION D,
of a SINAMICS S110/S120 Control Unit, and selected terminal modules can be
interconnected symbolically.
Table 4- 1 Control units that support a symbolic assignment
Module Supports symbolic assignment
SIMOTION D
• SIMOTION D410-2
• SIMOTION D410
• SIMOTION D4x5-2
• SIMOTION D4x5
• As of SIMOTION V4.3
• As of SIMOTION V4.2
• As of SIMOTION V4.2
• As of SIMOTION V4.2
Controller Extension
• CX32-2
• CX32
As of SIMOTION V4.2
SINAMICS S110 CU305 As of SINAMICS V4.3
SINAMICS S120
• CU310-2
• CU310
• CU320-2
• CU320
• As of SINAMICS V4.4
• As of SINAMICS V2.6.2
• As of SINAMICS V4.3
• As of SINAMICS V2.6.2
Refer also to
Only the drive configuration by means of symbolic assignment is described in this
documentation.
The documentation of older SIMOTION versions can be found on the Internet at the
following Internet address (http://support.automation.siemens.
com/WW/view/en/40211807) .
For further information on the configuration of the TO axis and TO external encoder, refer to
the
TO Axis Electric/Hydraulic, External Encoder
Function Manual.
