3.11.2 Parallel drawing before the machining of the workpiece
Before machining the workpiece on the machine, you can graphically
display the execution of the program on the screen in order to easily
monitor the result of the programming.
Simultaneous recording is a software option.
You can replace the programmed feedrate with a test-run feedrate in
order to control the execution speed (see Sec. "Establishing the test-
run feedrate").
In addition, you can interrupt or control the graphical execution, i.e.
the functions for program control such as "NC Stop," "Single Block,"
"Feedrate override," etc. are in effect.
If you would like to view the current program blocks again instead of
the graphical display, you can switch to the program view.
This function must be set-up via machine data.
Please also refer to the machine manufacturer's instructions.
 Load a program in "Machine Auto" mode (see Sec.
"Starting/stopping machining").
Program
test
 Press the "Prog. Cntrl." and "Program test" softkeys.
Dry run
feedrate
 Press the "Dry run feedrate" softkey, if the programmed feedrate
speed is to be replaced by a test-run speed.
 Press the "Real-sim." softkey.
Cycle Start
 Press the "Cycle Start" key.
Execution of the program will be displayed on the screen in graphical
form. The machine’s axes do not move.
Dry run
feedrate
 Press the "Dry run feedrate" softkey again, if the parallel drawing
is to run in the programmed feedrate speed. (The softkey is
deactivated again.)
Program
view
 Press the "Program view" softkey if you would like to switch away
from the graphical display into the program view of the "Machine
Auto" mode.
Recording of the graphical data continues in the background.
…
 Press one of the 4 softkeys for the graphical views, if you would
like to return to the graphical display.
