8
Tool Management 08/2005
8.2 Im
ortin
tools into the tool list
8
♥ Siemens AG, 2005. All rights reserved
8-362 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
8.2.2 Creating several cuts per tool
In the case of tools with more than one cutting edge, a separate set of
offset data is assigned to each cutting edge. You can set up a total of
9 edges for each tool.
There must be no gaps between the edges, i.e. if 3 edges are
required for a tool, these must be edges 1 to 3.
Follow the instructions given above to set up tools with more than one
edge in the tool list and enter the offset data for the 1st edge.
Cutting
edges >
New
edge
Then select the "Cutting edges" and "New edge" softkeys.
Instead of the input fields for the first cutting edge, the offset data
input fields for the second cutting edge are displayed.
Select another cutting edge position if appropriate.
Enter the offset data for the second cutting edge.
Repeat this process if you wish to create more tool edge offset
data.
Delete
edge
Select the "Delete edge" softkey if you want to delete the tool
edge offset data for an edge.
You can only delete the data for the edge with the highest edge
number.
D No. +
D No. –
By selecting softkey "D No. +" or "D No. –", you can display the offset
data for the edge with the next highest or next lowest edge number
respectively.
