Siemens SINUMERIK 840DE SL Operation/Programming

2
08/2005 Setting Up the Machine
2.8 Manual mode
2
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 2-81
2.8.3 Positioning the axes
In manual mode, you can traverse the axes to certain positions, in
order to implement simple machining sequences.
The feedrate/rapid traverse override is in effect during the traversing.
 If required, select a tool (see Sec. "Selecting a tool and spindle").
Jog
 Select the "Position" softkey in "Machine Manual" mode.
 Enter the target position for the axis or axes to be traversed.
Rapid
traverse
 Specify the desired value for the feedrate F.
-or-
 Press the "Rapid traverse” softkey.
Cycle Start
 Press the "Cycle Start" key.
The axis is traversed to the specified target position. If target positions
for several axes were specified, the axes are simultaneously
traversed.
