Siemens SINUMERIK 840DE SL Operation/Programming

5
ShopTurn Functions 08/2005
5.4 Contour turnin
g
5
♥ Siemens AG, 2005. All rights reserved
5-230 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
5.4.8 Grooving residual material
The "Grooving residual material" function is used when you want to
machine the material that remained after grooving along the contour.
During grooving along the contour, ShopTurn automatically detects
any residual material and generates an updated blank contour.
Material that remains as part of the finishing allowance is not residual
material. The "Grooving residual material" function allows you to
remove unwanted material with a suitable tool.
The "Grooving residual material" function is a software option.
Grooving
resid.
¾ Press the "Contour turning" and "Grooving resid." soft keys.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Machining
type
Roughing
Finishing
Stock removal
direction
Stock removal direction: Longitudinal or transverse
Machining side Machining side:
For stock removal in longitudinal direction: External or internal
For stock removal in transverse direction: end face or rear side
D Infeed depth for roughing (inc.) mm
XDA 1. grooving limit tool (inc) – (end face or rear face only) mm
XDB 2. grooving limit tool (inc) – (end face or rear face only) mm
U Finishing allowance in X and Z direction (inc) – (roughing only) – (alternative to UX
and UZ)
mm
UX Finishing allowance in X direction (inc) – (roughing only) – (alternative to U) mm
UZ Finishing allowance in Z direction (inc) – (roughing only) – (alternative to U) mm
Stock
allowance
Compensation allowance for contour or not – (finishing only)
U1 Compensation allowance in X and Z direction (inc) – (with allowance only)
Positive value: Compensation allowance is not removed
Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
DI Distance after which feed interruption occurs - (only for roughing) mm
Set machining
area limits
Limit machining area or not
XA Limit X (abs) – (with limited machining area only) mm
XB Limit X (abs or inc) – (with limited machining area only) mm
ZA Limit Z (abs) – (with limited machining area only) mm
ZB Limit Z (abs or inc) – (with limited machining area only) mm
N Number of grooves
