1.2 Workstation
In addition to the lathe with CNC/positioning control, a ShopTurn
workstation also has an operator panel and machine control panel.
Turning machine
complete with control
Operator
panel
Machine
control panel
Workstation configuration
Turning machine
You can use ShopTurn on a single-slide lathe with three axes, of a
main spindle, of a tool spindle, and of a counter-spindle.
PLC
ShopTurn runs on the SINUMERIK 840D sl CNC-controller with
ShopTurn on NCU (HMI Embedded) and PCU 50.3 (HMI Advanced).
Operator panel
Communication with ShopTurn is done via the operator panel.
Machine control panel
You operate the lathe using the machine control panel.
