2.8.5 Settings for manual mode
For manual mode, you can select the central machine functions and
work offsets and set the unit of measurement.
Machine functions (M-functions) are functions such as "Close door" or
"Release collet," for example, that were made available as extras by
the machine manufacturer.
Please also refer to the machine manufacturer's instructions.
In manual mode, you can display the axis positions and distance-
defining parameters either in "mm" or "inches". However, tool offsets
and zero-point offsets remain in the original unit of measure, in which
the machine was set (see Sec. "Switching the Unit of Measure
(Millimeters/Inches)").
Selecting an M function
Jog
Select the "T, S, M" softkey in "Machine Manual" mode.
Enter the number of the desired M function in the "Misc M fct."
parameter field.
Refer to the machine manufacturer's table for the correlation
between the meaning and number of the function.
Example:
M function Description
... ...
M88 Close door
... ...
"88" must be entered in the input field,
so that the door will be closed.
The M function will be active the next time you press the "Cycle Start"
key.
Work offset: Selection
Jog
Select the "T, S, M" softkey in "Machine Manual" mode.
Select the desired zero-point offset.
-or-
Work
offset
Press the "Work offset” softkey.
-and-
Position the cursor on the desired zero-point offset.
To Next Page
