5.5.7 Positions
If you want to mill a pocket, spigot or longitudinal slot at more than one
position, you must program a separate positioning block.
You must set "Pos. Pattern" for the milling cycle if you want to mill at
more than one position.
Position pattern
You will find further information about freely definable positions or
position patterns in the Section "Drilling".
Positions >
¾ Press the "Drilling" and "Positions" soft keys.
...
¾ Select the required position pattern via soft key.
¾ Then proceed as described in the Section "Drilling".
