Initial Inspections
3-12 7SJ62 Manual
C53000-G1140-C121-1
Date and Time
Setting
To enter the date and time:
q
Click on 'HYLFH in the menu bar. See Figure 3-11.
q
Select 6HW&ORFN.
Figure 3-11 DIGSI
®
4 — Selection of the Option 6HW&ORFN
The dialog field 6HWFORFNGDWHLQGHYLFH opens. The field shows the present
date and the approximate present time according to the device. The day of the week
is automatically derived from the date and cannot be edited.
• Edit the input fields 'DWH and 7LPH. The format depends on your regional settings
of the PC. See Figure 3-12.
Date: mm/dd/yyyy or dd.mm.yyyyy
Time: hh.mm.ss
Click 2. to download the entered values to the device. The former values are
changed and the dialog field is closed.
Figure 3-12 DIGSI
®
4 — Dialog Field: 6HWFORFNGDWHLQGHYLFH
