7.5.2 Reset
RESET
How the outputs are reset depends on the "Reset response" parameter (see Chapter "Reset
response (Page 281)").
The following settings can be selected:
• Automatic reset (Memory = O / Mem = no)
The device is reset automatically as soon as a previously occurring error has been dealt with.
• Manual RESET (Memory = I / Mem = yes)
To reset the devices with digital setting, it is necessary to press both arrow keys
simultaneously for more than 2.5 s after removal of the cause of error. If the cause of the error
has not been removed, a new error message appears immediately. Alternatively, the devices
can be reset by switching the rated control supply voltage on and o󹪜.
3UG4621/3UG4622 current monitoring relays
7.5 Diagnostics
SIRIUS 3UG4 / 3RR2 monitoring relay
130 Equipment Manual, 07/2021, NEB927043002000/RS-AD/005
