4.3 Performance features of current monitoring relays
Table 4-2 Performance features of 3RR2 current monitoring relays with analog setting
Functions/Parameters Current monitoring relays with analog setting
3RR2141-.A.30 3RR2142-.A.30 3RR2143-.A.30
Rated current 1.6 to 16 A 4 to 40 A 8 to 80 A
Frequency range 50/60 Hz AC 50/60 Hz AC 50/60 Hz AC
Supply voltage U
s
• -.AA30: 24 V AC/DC
• -.AW30: 24 to 240 V AC/DC
Monitoring for current over‐
shoots and/or undershoots
2-phase 2-phase 2-phase
Contacts 1 CO contact 1 CO contact 1 CO contact
Table 4-3 Performance features of 3RR2 current monitoring relays with digital setting
Functions/Parameters Current monitoring relays with digital setting
3RR2241-.F.30 3RR2242-.F.30 3RR2243-.F.30
Rated current 1.6 to 16 A 4 to 40 A 8 to 80 A
Frequency range 20 to 400 Hz AC 20 to 400 Hz AC 20 to 400 Hz AC
Supply voltage U
s
• -.FA30: 24 V AC/DC
• -.FW30: 24 to 240 V AC/DC
Monitoring for current over‐
shoots and/or undershoots
3-phase 3-phase 3-phase
Contacts 1 CO contact/1 semiconduc‐
tor output
1 CO contact/1 semiconduc‐
tor output
1 CO contact/1 semiconduc‐
tor output
4.3.1 General data
Table 4-4 General data for 3RR2 current monitoring relays
Feature Bene󹪝t 3RR21 Basic,
analog setting
3RR22 Standard,
digital setting
Sizes
• The devices are matched to the dimensions, connections and
technical features of the other devices in the SIRIUS modular
system.
• The devices permit mounting of slim-line and compact load
feeders in widths of 45 mm (S00 and S0) or 55 mm (S2).
• The devices make con󹪝guration easier.
S00, S0, S2 S00, S0, S2
Current range
• The devices are matched to the other devices in the SIRIUS
modular system
• Just 1 option per size with a wide setting range makes con‐
󹪝guration easy.
S00: 1.6 to 16 A
S0: 4.0 to 40 A
S2: 8.0 to 80 A
S00: 1.6 to 16 A
S0: 4.0 to 40 A
S2: 8.0 to 80 A
3RR2 current monitoring relays
4.3 Performance features of current monitoring relays
SIRIUS 3UG4 / 3RR2 monitoring relay
52 Equipment Manual, 07/2021, NEB927043002000/RS-AD/005
