Siemens SIRIUS 3UG4 User Manual

References
A
Further references
You will 󹪝nd further information on the 3RR2 and 3UG4 monitoring relays on the Internet (
http://
support.automation.siemens.com/WW/view/en/20356134/133300).
In addition to this manual, please refer to the operating instructions and manuals for any
accessories. You can download the relevant documentation from the Internet (http://
www.siemens.com/sirius/manuals). Simply enter the article number of the relevant item into
the search 󹪝eld.
Operating instructions
Title Article number
SIRIUS monitoring relay for polyphase current monitoring S00 / S0
(3RR21)
3ZX1012-0RR21-1AA1
SIRIUS monitoring relay for polyphase current monitoring S2 (3RR2143) 3ZX1012-0RR21-4AA1
SIRIUS monitoring relay for polyphase current monitoring S00 / S0
(3RR22)
3ZX1012-0RR22-1AA1
SIRIUS monitoring relay for polyphase current monitoring S2 (3RR2243) 3ZX1012-0RR22-4AA1
SIRIUS monitoring relay for level monitoring of conductive liquids
(3UG4501)
3ZX1012-0UG45-0BA1
SIRIUS monitoring relay for phase sequence monitoring (3UG4511) 3ZX1012-0UG45-3AA1
SIRIUS monitoring relay for phase sequence and phase failure monitoring
(3UG4512)
3ZX1012-0UG45-2AA1
SIRIUS monitoring relay for phase sequence and undervoltage monitor‐
ing (3UG4513)
3ZX1012-0UG45-1AA1
SIRIUS monitoring relay for phase sequence, asymmetry, and undervolt‐
age monitoring (3UG4614)
3ZX1012-0UG46-6AA1
SIRIUS monitoring relay for three-phase line monitoring (3UG4615 and
3UG4616)
3ZX1012-0UG46-1AA1
SIRIUS monitoring relay for three-phase line monitoring with phase cor‐
rection (3UG4617 and 3UG4618)
3ZX1012-0UG46-3AA1
SIRIUS monitoring relay for single-phase current monitoring (3UG4621
and 3UG4622)
3ZX1012-0UG46-2AA1
SIRIUS monitoring relay for residual current monitoring, with transform‐
er 3UL22 (3UG4624)
3ZX1012-0UG46-2BA1
SIRIUS monitoring relay for residual current monitoring, with 3UL23
(3UG4625) transformer
3ZX1012-0UG40-0AA0
SIRIUS monitoring relay for single-phase voltage monitoring (3UG4631
and 3UG4632)
3ZX1012-0UG46-5AA1
SIRIUS monitoring relay for single-phase voltage monitoring, self-pow‐
ered (3UG4633)
3ZX1012-0UG46-4AA1
SIRIUS 3UG4 / 3RR2 monitoring relay
Equipment Manual, 07/2021, NEB927043002000/RS-AD/005 279
