Scale parameters and functions
8.3 DR 3 calibration parameters
SIWAREX WP321
46 Manual, 07/2014, A5E33715669A-02
8.3
DR 3 calibration parameters
The calibration parameters need to be checked and if necessary modified for all scales.
The scale is basically defined by calibration parameters and calibration operation.
Procedure
● Check all parameters and modify them as required.
● Transfer the DR 3 data record from SIWATOOL to the scale.
● Calibrate the scale.
● Transfer the DR 3 data record from the scale to SIWATOOL.
Table 8- 1 Assignment of data record 3
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Data record
number
Contains no. of data record USHORT 2 r 3 - -
Length Data record length information USHORT 2 r 124 - -
Application Information about which application
the DR belongs to
USHORT 2 r 201 - -
Version iden-
tifier
Information on the current data rec-
ord version
USHORT 2 r 1 1 65 635
Scale name
header
Maximum length and actual length of
string for scale name
UBYTE[2] 2 rw 12,12 - -
Scale name
(Page 48)
Scale name specified by user CHAR[12] 12 rw " " - -
Unit of
weight head-
er
Maximum length and actual length of
string for unit of weight (e.g.: g, kg, t,
...)
UBYTE[2] 2 rw 04,04 - -
Unit of
weight
(Page 48)
1)
Unit of weight CHAR[4] 4 rw "kg••" - -
Gross identi-
fier header
Maximum length and actual length of
string for unit of weight
UBYTE[2] 2 rw 02,02 - -
Gross identi-
fier
(Page 48)
Abbreviation of gross
(B or G), only one byte is used!
CHAR[2] 2 rw "B" "B" "G"
Reserve Reserve USHORT 8 rw 0 - -
Maximum
weighing
range
(Page 49)
1)
Maximum weight FLOAT 4 rw 100 > wb_min*
ZIF.step
maximum
number
range
Calibration
weights 0, 1,
2 and cali-
bration digits
Calibration weight 0
1)
(usually the
zero point)
FLOAT 4 rw 0 1 9 999 999
Calibration weight 1
1)
FLOAT 4 rw 100 1 9 999 999
Calibration weight 2 FLOAT 4 rw 0 1 9 999 999
