Scale parameters and functions
8.10 DR 13 RS485 parameters
SIWAREX WP321
Manual, 07/2014, A5E33715669A-02
69
The parameters which define the response of the RS485 interface are specified in data
record DR 13. If the interface is not used, the default values can be retained.
● Check the parameters and modify them as required
● Transfer the data record to the scale
Table 8- 7 Assignment of data record 13
Data record
number
Contains no. of data record USHORT 2 r 13 - -
Length Data record length information USHORT 2 r 24 - -
Application Information about which applica-
tion the data record belongs to
USHORT 2 r 201 - -
Version iden-
tifier
Information on the current data
record version
USHORT 2 r 1 1 65 635
RS485 pro-
tocol
(Page 70)
0: No protocol
2: SIEBERT display
USHORT 2 rw 1 0 2
RS485 baud
rate
(Page 70)
0: 9 600 bps
1: 19 200 bps
2: 38 400 bps
3: 57 600 bps
4:115 000 bps
USHORT 2 rw 3 0 6
RS485 char-
acter parity
(Page 70)
Character parity
0: Even
1: Odd
BIT 2 rw 0 0 1
Bit 1 BIT 0 rw 0 0 1
Bit 2 BIT 0 rw 0 0 1
Reserve (13
bits)
Reserve BIT 0 rw 0 0 1
Reserve Reserve USHORT 2 rw 20 1 255
Decimal
place for
Siebert indi-
cator
(Page 70)
Decimal place for Siebert display SHORT 2 rw 0 - -
Reserve Reserve USHORT 2 rw 0 - -
Reserve Reserve FLOAT 4 rw 0 - -
