Scale parameters and functions
8.9 DR 10 load cell parameters
SIWAREX WP321
Manual, 07/2014, A5E33715669A-02
67
DR 10 load cell parameters
The parameters of the analog load cells must be checked prior to the automatic calibration
and modified if necessary. Only the parameters identified by bold font and asterisk (*) need
be entered.
● Check the parameters and modify them as required
● Transfer the data record to the scale
● Adjust the scales
Table 8- 6 Assignment of data record 10
Data record
number
Contains no. of data record USHORT 2 r 10 - -
Length Data record length information USHORT 2 r 44 - -
Application Information about which application
the DR belongs to
USHORT 2 r 201 - -
Version identifi-
er
Information on the current data
record version
USHORT 2 r 1 1 65 635
Reserve USHORT 2 rw 1 1 6
50/60 Hz tog-
gling (Page 68)
50/60 Hz toggling USHORT 2 rw 0 0 1
Number of
support points
(Page 68)
1)
Number of support points USHORT 2 rw 0 0 8
Reserve USHORT 2 rw 0 0 0
Load cell char-
acteristic value
(Page 68)
1)
Characteristic value of the load cell
(n) [mV/V], the mean value is used
if there is more than one cell.
FLOAT 4 rw 2 > 0.1 10
Reserve FLOAT 4 rw 0
Rated load of a
load cell
(Page 68)
1)
Rated load of a load cell FLOAT 4 rw 60 - -
Reserve Reserve FLOAT 4 rw 0 - -
Reserve Reserve FLOAT 4 rw 0 - -
Reserve Reserve SHORT 2 rw 0 - -
Reserve Reserve USHORT 2 rw 0 - -
Reserve Reserve FLOAT 4 rw 0 - -
1)
Parameter for calculation of calibration points with theoretical calibration
