Scale parameters and functions
8.10 DR 13 RS485 parameters
SIWAREX WP321
70 Manual, 07/2014, A5E33715669A-02
8.10.1
RS485 protocol
This parameter defines the protocol for communication via the RS485 interface. The
SIWATOOL program does not require any presettings.
Value
Protocol
0 No communication/protocol
2 SIEBERT display
8.10.2
RS485 baud rate
This parameter defines the baud rate for the RS485 interface.
Value
Baud rate
0 9 600 bps
1 19 200 bps
2 38 400 bps
3 57 600 bps
4 115 000 bps
8.10.3
RS485 character parity
This parameter defines the character parity for the RS485 interface.
Value
Character parity
0 Even
1 Odd
8.10.4
Decimal place for Siebert indicator
A fixed decimal place must be specified if a Siebert indicator is used. The following values
are permitted: 0 ... 4
