Command lists
SIWAREX WP321
92 Manual, 07/2014, A5E33715669A-02
83 Perform calibration check The command calculates the theoretical digital val-
ues in relation to the calibration weights using the
load cell parameters from data record 10 and the
adjustment weights 0, 1 and 2 from data record 3.
These theoretical digits are output in data record 4.
The function can be used to carry out a plausibility
check for the calibration digits in data record 3
which were determined when calibrated using
standard weights.
701 Increased resolution Activate increased resolution on main display (x 10) x
705 Display current tare weight Display current tare weight on main display x
710 Activate standard display Activate standard display gross/net x
711 G/N display Display gross/net weight on main display x
712 N display
713 G display
714 N process value Display net process weight on main display x
715 B process value Display gross process weight on main display x
871 Show serial number The serial number of the module is displayed
875 Display FW version Show firmware version in current display x
Basic functions for weighing commands
1001 Set to zero Set to zero x
1011 Tare Tare x
1012 Delete tare Delete current tare weight x
1013 Tare specification valid Activate specification of tare weight x
1016 S7 tare specification valid Activate specification of S7 tare weight
The following commands can be triggered in the scale data block SCALE_DB in the area
CMD1 to CMD3:
