2-1
DSR-2000A/2000AP
Start
Determination of
installation place
Unpacking
Rack mounting
Connectors
Initial setup
Operation check
END
· · · If an error message is shown on the time counter, refer to
“Section 4. Error Message” in service manual.
· · · 2-2. Operational Environment
· · · 2-3. Operating Voltage
· · · 2-4. Installation Space
· · · 2-5. Supplied Accessories
· · · 2-7. Mounting
· · · 2-8-1. Connectors/Cables
· · · 2-8-2. Input/Output Signals of the Connectors
· · · 2-9. Installation Setup and Adjustment
Be sure to install the DSR-2000A/2000AP in location satisfying the required operational environment described below to
assure the DSR-2000A/2000AP superior performance and to maintain the excellent serviceability and accessibility.
2-1. Installation Procedure
2-2. Operational Environment
. Operating temperature : +5 dC to +40 dC
. Humidity : 80 % or less
. Storage temperature : _20 dC to +60 dC
. Locations to avoid : . Areas where the unit will be exposed to direct sunlight or any other strong lights.
. Dusty areas or areas where it is subject to vibration.
. Areas with strong electric or magnetic fields.
. High-temperature environment.
(Good air circulation is essential to prevent internal heat build-up. Place the unit in location
with sufficient air circulation. Do not block the ventilation holes on the sides of the cabinet
and the rear panel.)
. Horizontal condition : within ±30 d
2-3. Operating Voltage
. Power voltage : AC 100 V to 240 V
. Power frequency : 50/60 Hz
. Power consumption : 120 W
Section 2
Installation
To Next Page
