DSR-2000A/2000AP
7-15. Rail Assembly Replacement
Outline
Replacement
Moving the S/T reel tables
Removing the S tension regulator assembly
Removing the T drawer arm assembly
Removing the RMP retainer (T1) assembly
Removing the head cleaner assembly
Removing the rail assembly
Reattaching the rail assembly
Reattaching the head cleaner assembly
Reattaching the RMP retainer (T1) assembly
Reattaching the T drawer arm assembly
Reattaching the S tension regulator assembly
Checking the threading/unthreading performance
Cleaning the tape guide
Adjustment after replacement
TENSION adjustment
Tape path adjustment
Note
Use extreme care not to scratch the drum and the tape guide when replacing the rail
assembly.
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Cleaning cloth : 3-184-527-01
. Cleaning fluid : 9-919-573-01
. Tweezers
To Next Page
