Sony DSR-2000AP Service Manual

2-5
DSR-2000A/2000AP
2-8. Connectors
2-8-1. Connectors/Cables
When external cables are connected to the connector on a connector panel during maintenance, the following (or equiva-
lents) must be used.
Connectors on DSR-2000A/2000AP Side Connector/Cable
Panel indication Designation Sony Part No.
ANALOG IN BNC, MALE 1-560-069-11
REF. VIDEO IN
TIME CODE IN
VIDEO IN
COMPONENT VIDEO IN
S VIDEO IN YC-15 V (1.5 m) optional accessory
AUDIO IN CH-1/2/3/4 XLR 3P, MALE 1-508-084-11
ANALOG OUT BNC, MALE 1-560-069-11
REF. VIDEO OUT
TIME CODE OUT
VIDEO OUT
COMPONENT VIDEO OUT
MONITOR AUDIO PIN PLUG Standard Product
S VIDEO OUT YC-15 V (1.5 m) optional accessory
AUDIO OUT CH-1/2/3/4 XLR 3P, FEMALE 1-508-083-11
i.LINK IEEE1394 6P (1 m) 1-782-408-21
IEEE1394 6P (3.5 m) 1-791-184-11
SDI INPUT BNC, MALE 1-560-069-11
SDI OUTPUT BNC, MALE 1-560-069-11
SDTI (QSDTI) INPUT BNC, MALE 1-560-069-11
SDTI (QSDTI) OUTPUT BNC, MALE 1-560-069-11
HD SDI OUT (DSBK-2020) BNC, MALE 1-560-069-11
DIGITAL AUDIO (AES/EBU) BNC, MALE 1-560-069-11
INPUT CH-1/2, CH-3/4
OUTPUT CH-1/2, CH-3/4 BNC, MALE 1-560-069-11
VIDEO CONTROL D-SUB 15P, FEMALE 1-561-610-21
CONTROL PANEL D-SUB 15P, MALE 1-561-651-11
REMOTE-IN D-SUB 9P, MALE 1-560-651-11
REMOTE-OUT D-SUB 9P, MALE 1-560-651-11
HEADPHONES PIN PLUG Standard Product
