DSR-2000A/2000AP
7-14. TG8 Arm Assembly Replacement
Outline
Replacement
Replacing the TG8 arm assembly
Cleaning the tape guide
Adjustment after replacement
Checking the tape path adjustment
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Washer extracting fixture (A) : J-6082-234-A
. Washer mounting fixture Ø1.5 : J-6082-231-A
. Cleaning cloth : 3-184-527-01
. Cleaning fluid : 9-919-573-01
. Tweezers
