7-36
DSR-2000A/2000AP
7-12. T Drawer Arm Assembly Replacement
Outline
Replacement
Removing the T drawer arm assembly
Checking the mounting position of the T gear
Reattaching the T drawer arm assembly
Cleaning the tape guide
Adjustment after replacement
Checking the tape path adjustment
Note
Use extreme care no to scratch the drum when replacing the T drawer arm assembly.
Preparation
1. Let the unit into the unthreading position.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Cleaning cloth : 3-184-527-01
. Cleaning fluid : 9-919-573-01
. Tweezers
To Next Page
