7-26
DSR-2000A/2000AP
7-9. Reel Motor (S) Assembly Replacement
Outline
Replacement
Removing the MD cover
Disconnecting the connector
Moving the S/T reel tables
Removing the RMP (S1) retainer assembly
Replacing the reel motor (S) assembly
Reattaching the RMP (S1) retainer assembly
Reconnecting the connector
Checking the performance
Reattaching the MD cover
Adjustment after replacement
S-RELL ONLY adjustment
TENSION adjustment
Tape path adjustment
Preparation
1. Set the unit to the unthreading end status.
2. Power off the unit.
3. Remove the top panel. (Refer to Section 3-3.)
4. Remove the bottom panel. (Refer to Section 3-3.)
5. Remove the right side panel. (Refer to Section 3-3.)
6. Remove the cassette compartment. (Refer to Section 3-4.)
Tools
. Torque screwdriver’s bit (for M1.4) : J-6325-110-A
. Torque screwdriver’s bit (for M2) : J-6325-380-A
. Torque screwdriver (for 3 kgf.cm) : J-6325-400-A
. Cleaning cloth : 3-184-527-01
. Cleaning fluid : 9-919-573-01
