3-31
DSR-2000A/2000AP
3-8. Fixtures and Tools list
Fig. Part No. Description Uses
1 J-6080-029-A Small adjustment mirror Video tracking adjustment
2 J-6082-231-A Washer mounting fixture (ø1.5) Parts replacement
3 J-6082-232-A Washer mounting fixture (ø1.2) Parts replacement
4 J-6082-233-A Washer mounting fixture (ø0.8) Parts replacement
5 J-6082-234-A Washer extracting fixture A Parts replacement
6 J-6082-236-A Washer fixture kit Parts replacement (Set of No.2 to No.5)
7 J-6082-362-A Tape guide adjustment driver Tape guide height adjustment
8 J-6082-373-A Torque cassette FWD/REV winding torque adjustment
9 J-6325-110-A Torque screwdriver‘s bit (M1.4) Parts replacement
!/ J-6325-380-A Torque screwdriver’s bit (M2) Parts replacement
!- J-6325-400-A Torque screwdriver (3 kg) Tightening screws
!= J-6443-710-A (CCW) Brake torque gauge (CCW) (DJ-371) Brake torque adjustment
![ J-6443-720-A (CW) Brake torque gauge (CW) (DJ-372) Brake torque adjustment
!] J-6444-930-A Extension board (DJ-493) Extension board for DSR-2000A
!\ J-6444-610-B Path Adjustment Board (DJ-461) For tape path adjustment RF envelope
detector fixture
!; J-6443-760-A System control/Servo Software version-up
download tool board (DJ-376)
!' 3-184-527-01 Cleaning cloth Cleaning
!, 7-432-114-11 Locking compound Locking compound
!. 7-662-001-39 Grease SG-941(20g) Parts replacement
@/ 8-967-999-02 Alignment tape XH2-1AST Tape path alignment (NTSC & PAL)
@- 8-967-999-22 Alignment tape XH5-1A2 (NTSC) Audio/video alignment (DVCAM)
8-967-999-26 Alignment tape XH5-1AP2 (PAL) Audio/video alignment (DVCAM for PAL)
@= 8-967-999-31 Alignment tape XH4-1A (NTSC) Audio/video alignment (DV)
@[ 9-919-573-01 Cleaning fluid Cleaning
