5A-10 BRAKES PIPE/HOSE/MASTER CYLINDER
Tightening Torque Specification
Special Tool
Fastening part
Tightening torque
N•m kg-m lb-ft
Brake flexible hose bolt (Brake caliper/2 way joint) 23 2.3 17.0
Brake hose / pipe bracket bolt 10 1.0 7.5
ABS actuator bracket bolt 10 1.0 7.5
Master cylinder attaching nut 13 1.3 9.5
Booster nut 13 1.3 9.5
Clevis nut 25 2.5 18.0
2-way joint mounting bolt 10 1.0 7.5
Brake pipe flare nut 16 1.6 12.0
Brake bleeder plug (Front caliper (M8)) 8 0.8 6.0
Brake bleeder plug (Wheel cylinder) 7.5 0.75 5.5
Wheel nut 100 10.0 72.5
09952-16021 09950-78220
Booster piston rod
adjuster
Flare nut wrench
(10 mm)
