10B-56 AIR BAG SYSTEM
Repairs and Inspections Required after an Accident
Accident with deployment/activation - component replacement
Certain air bag system components must be replaced. Those components are:
• Driver and passenger air bag (inflator) modules
– Replace with new one.
• Driver and Passenger seat belt pretensioners
– Replace with new one.
• SDM after detecting such collision as to meet deployment conditions
– Replace with new one.
• Forward sensors
– Replace with new one.
CAUTION:
• All air bag system components, including the electrical harness (component mounting points),
must be inspected after an accident. If any components are damaged or bent, they must be replaced
even if air bag system activation did not occur.
• Never use air bag system parts from another vehicle.
• Do not attempt to service the parts below. Service of these parts is by replacement only.
– Driver/Passenger air bag (inflator) modules, Driver/Passenger seat belt pretensioners
– Forward sensors
– SDM
– Contact coil and combination switch assembly
– Air bag wire harness
• Proper operation of the sensors and air bag system requires that any repairs to the vehicle struc-
ture return it to its original production configuration.
CAUTION:
After detecting one time of such collision as to meet deployment conditions, the SDM must not be
used.
Refer to “AIR BAG DIAGNOSTIC SYSTEM CHECK” when checking the SDM.
