Suzuki GRAND VITARA XL-7 User Manual

6-1-26 ENGINE GENERAL INFORMATION AND DIAGNOSIS (H27 ENGINE)
PNP SIGNAL (Transmis-
sion Range Switch) (for 4-
A/T)
With ignition switch ON, selector lever in “P”
or “N” position
P/N Range
✱
With ignition switch ON, selector lever in “R”,
“D”, “2” or “L” position
D Range
FUEL TANK LEVEL Ignition switch ON 0 – 100 % ✱
ELECTRIC LOAD Ignition ON, small light OFF OFF ✱
Ignition switch ON, small light ON ON ✱
VSS (Vehicle speed sen-
sor) (for 4-A/T)
At stop.
0 km/h 0 MPH ✱
GEAR POSITION (for 4-
A/T)
Ignition switch ON, selector lever is shifted at
“R”, “D”, “2” or “L” range and vehicle stops.
1st ✱
THROT POS LEVEL
(Throttle position level for
4-A/T)
“0” (about idle position), “1”,“2”,“3”,“4”,“5”,“6” or “7” (about full open)
appears according to throttle valve opening. ✱
SHIFT SOL #1 (A)
CON (Shift solenoid #1
command signal)
MON (Shift solenoid #1
monitor) (for 4-A/T)
Ignition switch ON
Selector lever is shifted at “P”, “R”, “N”, “D”,
“2” or “L” range.
Vehicle stops.
ON ✱
SHIFT SOL #2 (B)
CON (Shift solenoid #2
command signal)
MON (Shift solenoid #2
monitor) (for 4-A/T)
Ignition switch ON
Selector lever is shifted at “P”, “R”, “N”, “D”,
“2” or “L” range.
Vehicle stops.
OFF ✱
TCC SOL (for 4-A/T)
CON (Torque converter
clutch solenoid command
signal)
MON (Torque converter
clutch solenoid monitor)
Ignition switch ON
Selector lever is shifted at “P”, “R”, “N”, “D”,
“2” or “L” range.
Vehicle stops.
OFF ✱
TRANS RANGE
(for 4-A/T)
Ignition switch ON, selector lever is at “P”,
“R”, “N”, “D”, “2” or “L” range.
P, R, N, D, 2 or L ✱
BRAKE SW
(Brake, stop lamp, switch)
(for 4-A/T)
Ignition switch ON, Brake pedal is released. OFF
✱
Ignition switch ON, Brake pedal is
depressed.
ON
O/D OFF SW
(Overdrive cut switch)
Ignition switch ON, Overdrive cut switch OFF OFF
✱
Ignition switch ON, Overdrive cut switch ON ON
MODE SELECT SW
(Power/Normal change
switch) (for 4-A/T)
Ignition switch ON, P/N change switch is at
normal position.
NORMAL
✱
Ignition switch ON, P/N change switch is at
power position.
POWER
4WD-L SW
(4WD low switch)
Ignition switch ON, Transfer lever is shifted
at “4H” or “2H” position.
OFF
✱
Ignition switch ON, Transfer lever is shifted
at “4L” position.
ON
SCAN TOOL DATA CONDITION
NORMAL CONDITION/
REFERENCE VALUE
OTHER
