ENGINE GENERAL INFORMATION AND DIAGNOSIS (H27 ENGINE) 6-1-49
DTC CONFIRMATION PROCEDURE
1) Connect scan tool to DLC with ignition switch OFF.
2) Turn ON ignition switch and clear DTC, pending DTC and freeze frame data by using scan tool and run
engine at idle speed for 20 sec. or more.
3) Check DTC by using scan tool.
TROUBLESHOOTING
WARNING:
• When performing a road test, select a place where there is no traffic or possibility of a traffic acci-
dent and be very careful during testing to avoid occurrence of an accident.
• Road test should be carried out with 2 person, a driver and a tester, on a level road.
NOTE:
Check to make sure that following conditions are satisfied when using this “DTC CONFIRMATION
PROCEDURE”.
Intake air temp. : – 8°C (18°F) or higher
Engine coolant temp. : – 8 – 110°C (18 – 230°F)
Altitude (barometric pressure) : 2400 m, 8000 ft or less (560 mmHg, 75 kPa or more)
Step Action Yes No
1 Was “ENGINE DIAG. FLOW TABLE” per-
formed?
Go to Step 2. Go to “ENGINE DIAG.
FLOW TABLE” in this
section.
2 MAF sensor check :
1) Connect scan tool to DLC with ignition
switch OFF.
2) Start engine and check MAF value dis-
played on scan tool. (Refer to “SCAN TOOL
DATA” in this section for normal value.)
Is normal value indicated?
Intermittent trouble.
Check for intermittent
referring to “INTERMIT-
TENT AND POOR CON-
NECTION” in Section 0A.
Go to Step 3.
3 MAF sensor power supply check :
1) With ignition switch OFF, disconnect MAF
sensor coupler.
2) With ignition switch ON, check voltage
between E154-3 of MAF sensor coupler and
ground.
Is voltage 10 – 14 V?
Go to Step 4. Faulty “BLU/BLK” wire.
4 MAF sensor output voltage check :
1) With ignition switch OFF, connect MAF sen-
sor coupler.
2) Remove ECM (PCM) cover.
3) With ignition switch ON leaving engine OFF,
check voltage between C51-3-10 and C51-
3-5 terminal.
Is voltage 1.0 – 1.6 V?
Poor C51-3-10 or/C51-3-5
terminal connection.
If OK, substitute a known-
good ECM (PCM) and
recheck.
Faulty “PPL/WHT” wire.
Poor E154 coupler termi-
nal connection.
If wire and connection are
OK, substitute a known-
good MAF sensor and
recheck.
To Next Page
