ENGINE GENERAL INFORMATION AND DIAGNOSIS (H27 ENGINE) 6-1-97
DTC CONFIRMATION PROCEDURE
1) Connect scan tool to DLC with ignition switch OFF.
2) Turn ON ignition switch and clear DTC, pending DTC and freeze frame data by using scan tool.
3) Increase vehicle speed to 80 – 90 km/h (50 – 56 mph).
4) Keep above vehicle speed for 5 min. or more (Throttle valve opening is kept constant in this step).
5) Stop vehicle and check if pending DTC exists by using scan tool. If not, check if catalyst monitoring test has
completed by using scan tool. If not in both of above checks (i.e., no pending DTC and catalyst monitoring
test not completed), check vehicle condition (environmental) and repeat Step 3) through 5).
TROUBLESHOOTING
WARNING:
• When performing a road test, select a place where there is no traffic or possibility of a traffic acci-
dent and be very careful during testing to avoid occurrence of an accident.
• Road test should be carried out with 2 persons, a driver and a tester, on a level road.
NOTE:
Check to make sure that following conditions are satisfied when using this “DTC CONFIRMATION
PROCEDURE”.
• Intake air temp. : – 8°C (18°F) or higher
• Engine coolant temp. : – 8 – 110°C (18 – 230°F)
• Altitude (barometric pressure) : 2400 m, 8000 ft or less (560 mmHg (75 kPa) or more)
Step Action Yes No
1 Was “ENGINE DIAG. FLOW TABLE” per-
formed?
Go to Step 2. Go to “ENGINE DIAG.
FLOW TABLE” in this
section.
2 Exhaust system visual inspection :
1) Check exhaust system for leaks, damage
and loose connection.
Is it in good condition?
Go to Step 3. Repair or replace.
3 HO2S-2 output voltage check :
1) Check output voltage of HO2S-2 referring
Step 2 of DTC P0156 Diag. Flow Table.
Is check result satisfactory?
Replace warm up three
way catalytic converter.
Check “RED/YEL” and
“GRY/YEL” wires for open
and short, and connec-
tions for poor connection.
If wires and connections
are OK, replace HO2S-2.
To Next Page
