ENGINE GENERAL INFORMATION AND DIAGNOSIS (H27 ENGINE) 6-1-99
1) Connect scan tool to DLC with ignition switch OFF.
2) Turn ON ignition switch and clear DTC, pending DTC and freeze frame data by using scan tool.
3) Start engine and warm up it completely.
4) Increase vehicle speed to 55 km/h (35 mph) or more.
5) Keep driving above vehicle speed for 20 min or more (Change of vehicle speed is permitted in this step).
6) Release accelerator pedal, stop vehicle and run engine at speed for 2 min.
7) Check DTC and pending DTC by using scan tool.
TROUBLESHOOTING
Step Action Yes No
1 Was “ENGINE DIAG. FLOW TABLE” per-
formed?
Go to Step 2. Go to “ENGINE DIAG.
FLOW TABLE” in this
section.
2 Check EVAP canister purge system for opera-
tion referring to “EVAP CANISTER PURGE
SYSTEM INSPECTION” in this section.
Is check result satisfactory?
Intermittent trouble or
faulty ECM (PCM).
Check for intermittent
referring to “INTERMIT-
TENT AND POOR CON-
NECTION” in Section 0A.
Go to Step 3.
3 Check EVAP canister purge valve for resistance
referring to “EVAP CANISTER PURGE VALVE
INSPECTION” in this section.
Is resistance as specified?
“GRN/BLK” or “BLU/BLK”
circuit open or short.
If wire and connections
are OK, substitute a
known-good ECM (PCM)
and recheck.
Replace EVAP canister
purge valve.
To Next Page
