6A2-8 ENGINE MECHANICAL (H27 ENGINE)
16) Connect water hoses (3) to throttle body.
17) Connect accelerator cable (1) and A/T throttle cable (2) (for
A/T vehicle) to throttle body.
18) Install surge tank pipe (2) to intake manifold with new gas-
kets and intake air pipe (1) to throttle body.
19) Install surge tank cover (1).
20) Install air cleaner upper case.
21) Connect coupler to intake air temp. sensor and MAF sensor.
22) Install strut tower bar (1).
23) Check to ensure that all removed parts are back in place.
Reinstall any necessary parts which have not been rein-
stalled.
24) Refill cooling system referring to “COOLING SYSTEM
FLUSH AND REFILL” in Section 6B.
25) Connect negative cable at battery.
1
2
3
3
1
2
1
To Next Page
