ENGINE AND EMISSION CONTROL SYSTEM (SEQUENTIAL MULTIPORT FUEL INJECTION FOR H27 ENGINE) 6E2-33
REMOVAL
1) Disconnect negative (–) cable at battery and coupler (1) from
MAF sensor (3).
2) Remove air cleaner outlet hose (2) from throttle body and
MAF sensor (3).
3) Remove MAF sensor from air cleaner case.
INSTALLATION
1) Check MAF sensor seal (1) for deterioration and damage.
2) Install MAF sensor to air cleaner case.
3) Install air cleaner outlet hose.
4) Connect MAF sensor coupler securely.
5) Connect negative (–) cable to battery.
CAUTION:
• Don’t disassemble MAF sensor.
• Do not expose MAF sensor to any shock.
• Do not blow compressed air by using air gun or the
like.
• Do not put finger or any other object into MAF sensor.
Malfunction may occur.
