7E-10 DIFFERENTIAL (FRONT)
9) Using 2 large screwdrivers (4) as levers, pull out right side
drive shaft joint (1) from differential (2) and dismount housing
assembly from vehicle.
REMOUNTING
For remounting, reverse dismounting procedure and use the fol-
lowing tightening torque.
Tightening torque
Front drive shaft flange bolts (a) :
50 N·m (5.0 kg-m, 36.5 lb-ft)
Propeller shaft flange bolts (a) :
50 N·m (5.0 kg-m, 36.5 lb-ft)
Front mounting bracket bolts (a) :
50 N·m (5.0 kg-m, 36.5 lb-ft)
Rear mounting bracket bolts(a) :
50 N·m (5.0 kg-m, 36.5 lb-ft)
Rear mounting bolt (b) :
85 N·m (8.5 kg-m, 61.5 lb-ft)
Rear mounting bracket No.2 bolts (b) :
85 N·m (8.5 kg-m, 61.5 lb-ft)
After tightening all fasteners properly, fill hypoid gear oil as speci-
fied and check tightening of plugs with specification.
CAUTION:
During above work, use care not to cause damage to
drive shaft boot.
(b)
(b)
(a)
